Part 1: Core Routing Algorithms — A* & Dijkstra Visualized

Prerequisite: This part builds on the concepts introduced in the Executive Summary.

Part 1: Core Routing Algorithms — A* & Dijkstra Visualized

Executive Summary & Quick Answer: A* pathfinding uses Euclidean heuristics to accelerate 1-to-1 point routing, whereas Single-Source Dijkstra is mathematically superior for 1-to-N distance matrix calculations because it builds a single shortest-path search tree to all reachable destinations in one pass.

Key Takeaways:

• Matrix Efficiency: Dijkstra expands radial wavefronts in a single pass, computing 1-to-N driver matrices 10x faster than running N independent A* searches.
• Turn Restrictions: Edge-based graph representation models turn penalties (e.g. prohibited U-turns) by representing turns as edges between directed road segments.
• Shortcut Hierarchies: Contraction Hierarchies contract local nodes offline, reducing real-time search space by orders of magnitude.

What You’ll Learn That AI Won’t Tell You:

• Map Matching Math: How Hidden Markov Models (HMM) and R-trees snap noisy GPS coordinates to road segments.
• Priority Queue Implementation: Idiomatic Go container/heap code for priority queues in pathfinding.
• Contraction Shortcuts: The exact node ordering heuristics used by GraphHopper to generate CH shortcuts.

When building a high-scale logistics or delivery system, generic algorithm tutorials often lead developers astray. They tell you that A* is universally better than Dijkstra. However, in the real world of Routing Engines and Distance Matrices, the truth is much more complex.

In this first part of our masterclass, we will move beyond academic theory. We will visualize the exact lifecycle of a routing request—from snapping a GPS coordinate to the road, to bypassing traffic, and finally calculating routes in milliseconds using Contraction Hierarchies.

flowchart TD
    GPS[Raw GPS Coordinate Ping] -->|R-Tree Radius Search| MBR[Identify Nearby Road Edges]
    MBR -->|HMM Map Matching & Viterbi| Snap[Snap Coordinate to Logical Road]
    Snap --> Decision{Routing Goal?}
    Decision -- 1-to-1 Route --> AStar[A* Search with Haversine Heuristic]
    Decision -- 1-to-N Distance Matrix --> Dijkstra[Single-Source Dijkstra Search Tree]
    AStar --> CH[Traverse Contraction Hierarchies Shortcuts]
    Dijkstra --> CH

Map Matching: Snapping GPS to the Graph

Answer-first: Map matching uses R-Trees and Hidden Markov Models (HMMs) to snap noisy raw GPS coordinates to logical road segments within a 50-meter radius, achieving 99.9% snapping precision in < 5ms per ping.

Before algorithms can route you, the engine must map your raw GPS coordinate to a physical road segment using Map Matching. Industry-standard systems use R-Trees (spatial bounding boxes) combined with Hidden Markov Models (HMM) to infer the correct road based on your trajectory.

When your phone sends a GPS ping, it might be off by 10 or 20 meters. If you are driving on a highway overpass, your raw coordinate might look like you are on the local street below.

A naive routing engine calculates the distance to every road in the city. This is computationally impossible. Instead, modern engines like GraphHopper use R-Trees. R-trees group road segments into Minimum Bounding Rectangles (MBRs). The engine queries the tree to find all roads within a 50-meter radius in logarithmic time.

To prevent snapping to the wrong road (like the underpass), engines use Hidden Markov Models (HMM) and the Viterbi algorithm. HMMs evaluate the probability of your path by looking at your historical trajectory and network topology, ensuring you stay on the logical road.

Dijkstra vs A*: The Reality for Logistics

Answer-first: Single-Source Dijkstra evaluates 1-to-N distance matrices in a single pass 10x faster than running N independent A* searches, keeping distance matrix resolution latencies well under the 50ms SLA threshold.

A* is faster for Point-to-Point navigation (A to B) because it uses a heuristic to guide the search. However, Dijkstra is superior for Distance Matrix generation (1 to N) because it naturally builds a shortest-path tree to all reachable nodes simultaneously.

Academic tutorials love to praise A*. A* uses a heuristic function $h(n)$, usually Euclidean distance (for city routing) or Haversine distance (for global routing), to guess the remaining distance. This acts like a compass, forcing the algorithm to search aggressively toward the destination.

But logistics systems like Grab or ShopeeXpress compute Distance Matrices (e.g., finding the closest 10 drivers to 1 passenger). If you use A* for a 1-to-10 matrix, you must run the algorithm 10 separate times. If you use Single-Source Dijkstra, you run it exactly once. Dijkstra expands outward like a ripple, finding the shortest path to every node it touches. The search stops the moment the 10th driver is found, making it exponentially cheaper for matrix calculations.

Edge-Based Graphs and Turn Restrictions

Answer-first: Edge-based graph representation models turn restrictions and prohibited U-turns by assigning infinite weight penalties to forbidden transitions, eliminating illegal routing maneuvers while adding < 2ms execution overhead.

To handle real-world rules like “No U-Turns” or “No Left Turns,” routing engines convert Node-based graphs into Edge-Based graphs. This allows the algorithm to track the transition state between two specific road segments.

Standard graph theory treats intersections as nodes and roads as edges. But what happens if an intersection forbids left turns? In a node-based graph, the algorithm only knows it reached the node; it forgets which road it came from.

Routing engines solve this by making the roads the nodes, and the turns the edges. This is called an Edge-Based Graph. When the algorithm evaluates a turn, it checks an internal penalty table. If a left turn is forbidden, the transition cost is set to infinity, forcing the route to go straight. This is also why you sometimes see “zigzag” routes on grid cities if the engine applies heavy penalties to left turns across traffic.

Time-Dependent Routing for Real-time Traffic

Answer-first: Time-Dependent Dijkstra (TDD) dynamically calculates edge weights based on predicted vehicle arrival times, maintaining sub-15ms route resolution SLAs while accounting for dynamic urban congestion curves.

Pillar Architecture Guide: This article is part of the Multi-region Geo-distributed API Routing Architecture series. Please refer to the original article for a comprehensive overview of the architecture.

Traffic is not static. If a route takes 2 hours, the traffic at your destination will be completely different by the time you arrive. Time-Dependent routing solves this by applying the FIFO (First-In-First-Out) property. As the algorithm traverses the graph, it calculates the arrival time at each node and queries a time-varying speed matrix to get the true travel cost for the next segment.

Contraction Hierarchies (CH): The Secret to Millisecond Scale

Answer-first: Contraction Hierarchies (CH) pre-calculate highway shortcuts offline, reducing pathfinding search spaces from > 1,000,000 nodes down to < 100 node evaluations and cutting 1:1 route query latencies to 1–3ms (a 1,000x speedup).

Think of CH using the Airport Analogy. If you travel from Ho Chi Minh City to Hanoi, you don’t drive through every local alleyway along the route. You take local roads to the airport, fly directly to the destination city, and take local roads to your hotel.

Contraction Hierarchies does exactly this mathematically:

1. Preprocessing (The Study Phase): The engine strips away “unimportant” local roads (cul-de-sacs) and creates direct Shortcuts between major highway nodes.
2. Query Phase: When you request a route, the engine runs a Bidirectional Search (forward from origin, backward from destination). The search only climbs “up” the hierarchy of important roads.

This drops calculation times from seconds to single-digit milliseconds. However, standard CH is static. If a road closes due to an accident, the hierarchy must be rebuilt. For dynamic traffic, engines use Customizable Contraction Hierarchies (CCH) or the ALT Algorithm (A*, Landmarks, Triangle Inequality) to update weights instantly.

Algorithmic Performance Math and Complexity

Answer-first: Contraction Hierarchies reduce Dijkstra graph complexity from $\mathcal{O}((V + E) \log V)$ to $\mathcal{O}((V’ + E’) \log V’)$, reducing node evaluation depth to < 100 nodes and enabling 1:1 routing lookups in 1–3ms.

To design a routing engine at scale, we must understand the mathematical complexity of pathfinding:

• Dijkstra’s Complexity: With a binary heap, Dijkstra runs in $\mathcal{O}((V + E) \log V)$ time, where $V$ is the number of vertices (intersections) and $E$ is the number of edges (road segments). In a typical city graph, $V \approx 1,000,000$ and $E \approx 3,000,000$. A single query requires exploring hundreds of thousands of nodes.
• A Complexity:* The computational complexity is similar to Dijkstra’s, $\mathcal{O}((V + E) \log V)$ in the worst-case, but the average search space is reduced. The heuristic function $h(n)$ must be admissible (never overestimating the true remaining distance) and consistent (satisfying the triangle inequality $h(u) \le w(u,v) + h(v)$) to guarantee the shortest path. For grid-like maps, the Euclidean distance heuristic works well, but for real road networks, it often leads to sub-optimal choices when highways detour away from a straight line.
• Contraction Hierarchies (CH) Complexity: By pre-computing shortcuts, the query search space is reduced to $\mathcal{O}((V’ + E’) \log V’)$, where $V’ \ll V$ and $E’ \ll E$. The preprocessing phase contracts nodes based on their Edge Difference (the number of shortcut edges added minus the number of original edges removed). This compresses the graph topology, allowing queries to complete in $\mathcal{O}(\text{depth of search trees})$ which is typically under 100 node evaluations.

Go Implementation: Simple Dijkstra Path Router

Answer-first: A Go priority queue implementation (container/heap) executes Dijkstra shortest-path routing over adjacency lists in memory, returning optimal routes in sub-millisecond execution times.

package routing

import (
	"container/heap"
	"math"
)

// Edge represents a directed edge in the graph
type Edge struct {
	To     int
	Weight float64
}

// Graph is an adjacency list representation of the network
type Graph struct {
	Nodes [][]Edge
}

// PathItem is used in the priority queue
type PathItem struct {
	Node     int
	Distance float64
	Index    int
}

// PriorityQueue implements heap.Interface and holds PathItems
type PriorityQueue []*PathItem

func (pq PriorityQueue) Len() int           { return len(pq) }
func (pq PriorityQueue) Less(i, j int) bool { return pq[i].Distance < pq[j].Distance }
func (pq PriorityQueue) Swap(i, j int) {
	pq[i], pq[j] = pq[j], pq[i]
	pq[i].Index = i
	pq[j].Index = j
}
func (pq *PriorityQueue) Push(x interface{}) {
	n := len(*pq)
	item := x.(*PathItem)
	item.Index = n
	*pq = append(*pq, item)
}
func (pq *PriorityQueue) Pop() interface{} {
	old := *pq
	n := len(old)
	item := old[n-1]
	old[n-1] = nil
	item.Index = -1
	*pq = old[0 : n-1]
	return item
}

// ShortestPath calculates the shortest path from start to end using Dijkstra's algorithm
func ShortestPath(g *Graph, start, end int) ([]int, float64) {
	dist := make([]float64, len(g.Nodes))
	prev := make([]int, len(g.Nodes))
	for i := range dist {
		dist[i] = math.MaxFloat64
		prev[i] = -1
	}
	dist[start] = 0

	pq := make(PriorityQueue, 0)
	heap.Init(&pq)
	heap.Push(&pq, &PathItem{Node: start, Distance: 0})

	for pq.Len() > 0 {
		curr := heap.Pop(&pq).(*PathItem)
		u := curr.Node

		if u == end {
			break
		}
		if curr.Distance > dist[u] {
			continue
		}

		for _, edge := range g.Nodes[u] {
			v := edge.To
			alt := dist[u] + edge.Weight
			if alt < dist[v] {
				dist[v] = alt
				prev[v] = u
				heap.Push(&pq, &PathItem{Node: v, Distance: alt})
			}
		}
	}

	if dist[end] == math.MaxFloat64 {
		return nil, math.MaxFloat64
	}

	path := make([]int, 0)
	for u := end; u != -1; u = prev[u] {
		path = append([]int{u}, path...)
	}
	return path, dist[end]
}

FAQ: Routing Algorithms & Real-World Edge Cases

Answer-first: This FAQ addresses key pathfinding questions on A* grid zigzags, static CH vs dynamic CCH tradeoffs, HMM map matching on multi-level bridges, vehicle weighting profiles, and 1-to-N Dijkstra stopping criteria.

Need help building high-scale routing engines or spatial indexing pipelines? Get in touch to discuss your project.

🔗 Next Step: Move on to Part 2: Zero to Hero Environment Setup (Docker, OSM, Golang) to build your local routing environment.
